Series 2700 & 2800 Current to Pressure Transducer
Product Introduction
The Series 2700 and 2800 Current to Pressure Transducers are precision devices designed to convert variable current signals (4-20 mA) into proportional pneumatic outputs, ideal for controlling valve actuators, pneumatic positioners, and other industrial pneumatic equipment. Both series feature rugged NEMA 4X (IP65) enclosures for indoor/outdoor use and hold FM/CSA approvals for intrinsically safe operation. While the 2700 focuses on cost-effectiveness and high flow capacity, the 2800 incorporates advanced closed-loop feedback for enhanced stability in demanding environments.
Features
Economical Performance: Combines low startup cost, minimal air consumption (0.03 scfm at midrange), and reliable operation, making it a cost-effective choice for standard applications.
Versatile Plumbing: Input and output ports on both front and back enable flexible installation (remote or panel mounting).
High Flow Capacity: Integral volume booster delivers up to 12.0 scfm (at 100 psig supply), accelerating control speed in critical systems.
Easy Calibration: External zero and span adjustments simplify field calibration.
Intrinsically Safe: FM/CSA approved for Class I, II, III hazardous locations, ensuring safe use in explosive environments.
Technical Specs at a Glance
| Parameter | Series 2700 | Series 2800 |
| Input Signal | 4-20 mA | 4-20 mA |
| Air Supply | 5-100 psig (0.3-6.9 bar) | 5-100 psig (0.3-6.9 bar) |
| Output Ranges | 3-15 psig (0.2-1.0 bar); 6-30 psig (0.4-2.1 bar) | 3-15 psig (0.2-1.0 bar); 6-30 psig (0.4-2.1 bar) |
| Enclosure | NEMA 4X (IP65), chromate-treated aluminum | NEMA 4X (IP65), chromate-treated aluminum |
| Connections | 1/4" female NPT (pressure); 1/2" female NPT (electrical) | 1/4" female NPT (pressure); 1/2" female NPT (electrical) |
| Agency Approvals | CE, FM, CSA (intrinsically safe) | CE, FM, CSA (intrinsically safe) |
|
